AMD Radeon RX 5300

Memory size

3 GB

Memory type

GDDR6

FLOPS

TDP

100 W

Price

129 USD

Pixel Fillrate

52.64 GPixel/s

G3D Mark: 7532

Hashrate: No data

Description

AMD Radeon RX 5300 was released on May 28th, 2020. The video card is equipped with 3 GB of GDDR6 memory with a bandwidth of 168.0 GB/s. It uses a PCIe 4.0 x8 and has a 96 bit memory bus. AMD Radeon RX 5300 is powered by an RDNA 1.0 processor with 7 nm technology, 6400 million transistors, and has a die size of 158 mm². The card comes with connectors. The TDP (thermal design power) of this card is , and a power supply is recommended.

In terms of performance, the Pixel Rate is 52.64 GPixel/s, texture rate is 144.8 GTexel/s, and the device can perform . The video card is compatible with DirectX 12 (12_1), OpenGL version 4.6, OpenCL version 2.1, and Vulkan version 1.3.

Technical specifications

Graphics Processor

GPU Name:	AMD Radeon RX 5300
GPU Variant:	Navi 14 XE
Processor:	RDNA 1.0
Foundry:	TSMC
Technology:	7 nm
Transistors:	6400 million
Die Size:	158 mm²

General information

Release Date:	May 28th, 2020
Generation:	Navi (RX 5000)
Predecessor:	Vega
Successor:	Navi II
Production:	Active
Launch Price:	129 USD
Bus Interface:	PCIe 4.0 x8

Clock Speeds

Base Clock Speed:	1327 MHz
Boost Clock Speed:	1645 MHz
Memory Clock:	1750 MHz 14 Gbps effective

Memory specs

RAM:	3 GB
Type of memory:	GDDR6
Memory Bus:	96 bit
Memory Bandwidth:	168.0 GB/s

Render Config

Shading Units:	1408
TMUs:	88
ROPs:	32
Compute units:	22
L2 Cache:

Board specs

Slot Width:	Dual-slot
Length:	180 mm 7.1 inches
TDP:	100 W
Suggested PSU:	300 W
Outputs:	1x HDMI 2.13x DisplayPort 1.4a
Power Connectors:	1x 6-pin

Technology Support

DirectX:	12 (12_1)
OpenGL:	4.6
OpenCL:	2.1
Vulkan:	1.3

Theoretical Performance

Tests	Score	Reference (max)
Pixel Fillrate:	52.64 GPixel/s	691.2 GPixel/s (AMD Radeon RX )
Texture Fillrate:	144.8 GTexel/s	2074 GTexel/s (AMD Radeon RX )
FP16 (half):	(2:1)	(8:1) (AMD Radeon Instinct MI250X)
FP32 (float):		(NVIDIA GeForce RTX 4090 Ti)
FP64 (double):	289.5 GFLOPS (1:16)	(1:1) (AMD Radeon Instinct MI250X)
Unified Shaders:	1408	17408 (NVIDIA GeForce RTX 4090 Ti)
Texture Mapping Units:	88	880 (AMD Radeon Instinct MI250X)
Render Output Units:	32	256 (AMD Radeon RX )

Benchmarks Performance Tests

Tests	Score	Reference (max)
Passmark (G3D):	7532	39627 (NVIDIA GeForce RTX 4090)
PassMark (G2D):	806	1325 (NVIDIA GeForce RTX 4090)
OpenCL:	39363	229738 (NVIDIA GeForce RTX 3090 Ti)
Power Performance:	76.11	204 (AMD Radeon Pro 5600M)
